Compare Cranes. Choose Smarter.
Liebherr LR 11350 VS ACE TM 250 C Comparison
Liebherr LR 11350
₹ ₹ 60 L - 86 LL*
VS
ACE TM 250 C
₹ 70 L - 80 L
Liebherr LR 11350
₹60L
ACE TM 250 C
₹70L
Compare cranes to make an informed purchase decision.
Liebherr LR 11350
From ₹ 60 Lakh
ACE TM 250 C
From ₹ 70 Lakh
Engine
Engine Make
Cummins
Ashok Leyland
Engine Make
Cummins
Ashok Leyland
Engine Model
Cummins QSK23 860
H Series CRS
Engine Model
Cummins QSK23 860
H Series CRS
Engine Displacement
15000 cc
4000 cc
Engine Displacement
15000 cc
4000 cc
Engine Power
860 HP
165 HP
Engine Power
860 HP
165 HP
Maximum Torque
3525 Nm
450 Nm
Maximum Torque
3525 Nm
450 Nm
Fuel Type
Diesel
Diesel
Fuel Type
Diesel
Diesel
Overall Dimension & Weight
Overall Length
12543 mm
10500 mm
Overall Length
12543 mm
10500 mm
Overall Width
3500 mm
2500 mm
Overall Width
3500 mm
2500 mm
Overall Height
3655 mm
3400 mm
Overall Height
3655 mm
3400 mm
Wheel Base
N/A mm
4500 mm
Wheel Base
N/A mm
4500 mm
Min Ground Clearance
350 mm
300 mm
Min Ground Clearance
350 mm
300 mm
Operating Weight
290000 kg
25000 kg
Operating Weight
290000 kg
25000 kg
Boom & Lifting
Crane Type
Crawler lattice boom crane
Truck Mounted Telescopic Crane
Crane Type
Crawler lattice boom crane
Truck Mounted Telescopic Crane
Boom Type
Lattice main boom
Fully Hydraulic Telescopic Boom
Boom Type
Lattice main boom
Fully Hydraulic Telescopic Boom
Boom Length
150 m
9.5 - 30 m
Boom Length
150 m
9.5 - 30 m
Max Lifting Height
220 m
22 m
Max Lifting Height
220 m
22 m
Max Working Radius
164 m
19 m
Max Working Radius
164 m
19 m
Rated Capacity
Max Lifting Capacity
1350 t
25 t
Max Lifting Capacity
1350 t
25 t
Rated Load
1245 t
25 t
Rated Load
1245 t
25 t
Capacity at Min Radius
1350t@12
25 tons @ 3 m
Capacity at Min Radius
1350t@12
25 tons @ 3 m
Capacity at Max Radius
25.8@164
3 tons @ 24 m
Capacity at Max Radius
25.8@164
3 tons @ 24 m
Hydraulic System
Pump Type
Axial piston pumps (open‑loop)
Axial Piston Pump
Pump Type
Axial piston pumps (open‑loop)
Axial Piston Pump
Main Pump Capacity
220 Lpm
75 Lpm
Main Pump Capacity
220 Lpm
75 Lpm
Max Hydraulic Flow
280 Lpm
200 Lpm
Max Hydraulic Flow
280 Lpm
200 Lpm
System Pressure
350 bar
250 bar
System Pressure
350 bar
250 bar
Service Capacities
Engine Oil
17 L
15 L
Engine Oil
17 L
15 L
Rear Axle Oil
12 L
8 L
Rear Axle Oil
12 L
8 L
Transmission Oil
22 L
12 L
Transmission Oil
22 L
12 L
Hydraulic System
487 L
300 L
Hydraulic System
487 L
300 L
Fuel Tank
2000 L
200 L
Fuel Tank
2000 L
200 L
Cooling System
26 L
25 L
Cooling System
26 L
25 L
Steering & Brakes
Steering Type
Independent track steering (crab, pivot turns)
Power Steering
Steering Type
Independent track steering (crab, pivot turns)
Power Steering
Turning Radius
N/A m
8.5 m
Turning Radius
N/A m
8.5 m
Service Brake Type
Hydraulically actuated service braking via travel motors
Air Brakes
Service Brake Type
Hydraulically actuated service braking via travel motors
Air Brakes
Parking Brake Type
Spring‑applied / hydraulic release brake (tracks)
Spring Actuated, Air Released
Parking Brake Type
Spring‑applied / hydraulic release brake (tracks)
Spring Actuated, Air Released
Tyres
Tyre Size
350/80 R22.5
11.00 x 20 – 16 PR
Tyre Size
350/80 R22.5
11.00 x 20 – 16 PR
No. of Tyres
12
6
No. of Tyres
12
6
Electrical & General
Battery
24
24V / 120 Ah
Battery
24
24V / 120 Ah
Alternator Output
80 A
70 A
Alternator Output
80 A
70 A
Max Travel Speed
34 km/h
80 km/h
Max Travel Speed
34 km/h
80 km/h
Liebherr LR 11350
Pros
- Massive lifting capacity: ~1,350 t makes it one of the most capable crawler cranes worldwide.
- Very tall lifts: hook heights to ~220 m, good for super‑structure and offshore work.
- Flexible boom/jib combinations: Can be tailored to project needs.
ACE TM 250 C
Pros
- Rated 25 tonnes makes it suitable for construction, infrastructure, and industrial lifting tasks.
- 165 BHP diesel engine provides sufficient power for travel and lifting operations.
- Truck-mounted design with a 6×4 drive setup offers better on-road mobility and transport between sites without separate trailers.
