Liebherr LR 11000 VS SANY STC800C Comparison
Liebherr LR 11000
₹ ₹ 4.80 Cr - 6.19 CrL*
VS
SANY STC800C
₹ 3.45 Cr - 3.67 Cr
Liebherr LR 11000
₹480L
SANY STC800C
₹345L
Compare cranes to make an informed purchase decision.
Liebherr LR 11000
From ₹ 480 Lakh
SANY STC800C
From ₹ 345 Lakh
Engine
Engine Make
Liebherr (OEM crane engine)
Cummins
Engine Make
Liebherr (OEM crane engine)
Cummins
Engine Model
Liebherr V‑8 heavy‑duty diesel
ISL9
Engine Model
Liebherr V‑8 heavy‑duty diesel
ISL9
Engine Displacement
15000 cc
8900 cc
Engine Displacement
15000 cc
8900 cc
Engine Power
680 HP
345 HP
Engine Power
680 HP
345 HP
Maximum Torque
3000 Nm
1500 Nm
Maximum Torque
3000 Nm
1500 Nm
Fuel Type
Diesel
Diesel
Fuel Type
Diesel
Diesel
Overall Dimension & Weight
Overall Length
11500 mm
12500 mm
Overall Length
11500 mm
12500 mm
Overall Width
2800 mm
2500 mm
Overall Width
2800 mm
2500 mm
Overall Height
3600 mm
3500 mm
Overall Height
3600 mm
3500 mm
Wheel Base
N/A mm
6543 mm
Wheel Base
N/A mm
6543 mm
Min Ground Clearance
350 mm
300 mm
Min Ground Clearance
350 mm
300 mm
Operating Weight
1000000 kg
80000 kg
Operating Weight
1000000 kg
80000 kg
Boom & Lifting
Crane Type
Crawler lattice boom crane
Truck Crane
Crane Type
Crawler lattice boom crane
Truck Crane
Boom Type
Modular lattice main boom (S/P/W systems)
Telescopic
Boom Type
Modular lattice main boom (S/P/W systems)
Telescopic
Boom Length
168 m
10 - 45 m
Boom Length
168 m
10 - 45 m
Max Lifting Height
224 m
48 m
Max Lifting Height
224 m
48 m
Max Working Radius
184 m
45 m
Max Working Radius
184 m
45 m
Rated Capacity
Max Lifting Capacity
1000 t
80 t
Max Lifting Capacity
1000 t
80 t
Rated Load
100 t
80 t
Rated Load
100 t
80 t
Capacity at Min Radius
1000t@11
80 t @ 3 m
Capacity at Min Radius
1000t@11
80 t @ 3 m
Capacity at Max Radius
100@184
3.5 t @ 36 m
Capacity at Max Radius
100@184
3.5 t @ 36 m
Hydraulic System
Pump Type
Axial piston
Variable Displacement Piston Pump
Pump Type
Axial piston
Variable Displacement Piston Pump
Main Pump Capacity
220 Lpm
220 Lpm
Main Pump Capacity
220 Lpm
220 Lpm
Max Hydraulic Flow
400 Lpm
360 Lpm
Max Hydraulic Flow
400 Lpm
360 Lpm
System Pressure
320 bar
320 bar
System Pressure
320 bar
320 bar
Service Capacities
Engine Oil
50 L
30 L
Engine Oil
50 L
30 L
Rear Axle Oil
12 L
25 L
Rear Axle Oil
12 L
25 L
Transmission Oil
250 L
40 L
Transmission Oil
250 L
40 L
Hydraulic System
900 L
950 L
Hydraulic System
900 L
950 L
Fuel Tank
1500 L
400 L
Fuel Tank
1500 L
400 L
Cooling System
40 L
50 L
Cooling System
40 L
50 L
Steering & Brakes
Steering Type
Crawler steering
Hydraulic Power Steering
Steering Type
Crawler steering
Hydraulic Power Steering
Turning Radius
N/A Pivot Turns m
10.5 m
Turning Radius
N/A Pivot Turns m
10.5 m
Service Brake Type
Hydraulic / multi‑disc
Air-Over-Hydraulic Disc Brakes
Service Brake Type
Hydraulic / multi‑disc
Air-Over-Hydraulic Disc Brakes
Parking Brake Type
Spring‑applied, hydraulic release
Spring-Applied, Pneumatic Release
Parking Brake Type
Spring‑applied, hydraulic release
Spring-Applied, Pneumatic Release
Tyres
Tyre Size
N/A (crawler tracks)
12.00R20
Tyre Size
N/A (crawler tracks)
12.00R20
No. of Tyres
N/A (crawler tracks)
10
No. of Tyres
N/A (crawler tracks)
10
Electrical & General
Battery
24V
24V / 2×150Ah
Battery
24V
24V / 2×150Ah
Alternator Output
80 A
80 A
Alternator Output
80 A
80 A
Max Travel Speed
1.3 km/h
75 km/h
Max Travel Speed
1.3 km/h
75 km/h
Liebherr LR 11000
Pros
- Excellent maximum lifting capacity (~1,000 t) for industrial, wind‑energy and infrastructure projects
- Compact transport dimensions relative to capacity (3.5 m width)
- Advanced LICCON2 controls for safe, efficient operation
SANY STC800C
Pros
- 80 ton rated capacity with ~47.5 m telescopic boom + fixed jib extension for tall lifts and wide coverage.
- High‑power diesel engine (~324 kW / ~435 HP) suitable for both travel and heavy lifting operations.
- Truck‑mounted design (8×4) offers good travel speed (up to ~80 km/h typical) and flexibility between jobs.
