Compare Cranes. Choose Smarter.
ACE 40XW VS ZOOMLION QY55D Comparison
ACE 40XW
₹ ₹ 54 L - 58 L
VS
ZOOMLION QY55D
₹ 1.42 Cr - 1.44 Cr
Compare cranes to make an informed purchase decision.
ACE 40XW
From ₹ 54 Lakh
ZOOMLION QY55D
From ₹ 142 Lakh
Engine
Engine Make
Ashok Leyland H-series
Weichai
Engine Make
Ashok Leyland H-series
Weichai
Engine Model
H6ETI-CRS
WP10.336
Engine Model
H6ETI-CRS
WP10.336
Engine Displacement
3839 cc
9726 cc
Engine Displacement
3839 cc
9726 cc
Engine Power
180 HP
336 HP
Engine Power
180 HP
336 HP
Maximum Torque
450 Nm
1500 Nm
Maximum Torque
450 Nm
1500 Nm
Fuel Type
Diesel
Diesel
Fuel Type
Diesel
Diesel
Overall Dimension & Weight
Overall Length
11500 mm
13100 mm
Overall Length
11500 mm
13100 mm
Overall Width
2600 mm
2750 mm
Overall Width
2600 mm
2750 mm
Overall Height
3450 mm
3650 mm
Overall Height
3450 mm
3650 mm
Wheel Base
4200 mm
6000 mm
Wheel Base
4200 mm
6000 mm
Min Ground Clearance
350 mm
300 mm
Min Ground Clearance
350 mm
300 mm
Operating Weight
40000 kg
41870 kg
Operating Weight
40000 kg
41870 kg
Boom & Lifting
Crane Type
Pick & Carry Crane
Truck Mounted Hydraulic Crane
Crane Type
Pick & Carry Crane
Truck Mounted Hydraulic Crane
Boom Type
Telescopic Boom
Telescopic
Boom Type
Telescopic Boom
Telescopic
Boom Length
12.8 m – 30 m m
11 - 43 m
Boom Length
12.8 m – 30 m m
11 - 43 m
Max Lifting Height
32 m
43 m
Max Lifting Height
32 m
43 m
Max Working Radius
16 m
30 m
Max Working Radius
16 m
30 m
Rated Capacity
Max Lifting Capacity
40 t
55 t
Max Lifting Capacity
40 t
55 t
Rated Load
40 t
55 t
Rated Load
40 t
55 t
Capacity at Min Radius
40 tons @ 3 m
55 t @ 3 m
Capacity at Min Radius
40 tons @ 3 m
55 t @ 3 m
Capacity at Max Radius
8 tons @ 26 m
1.2 t @ 38 m
Capacity at Max Radius
8 tons @ 26 m
1.2 t @ 38 m
Hydraulic System
Pump Type
Gear Pump
Axial Piston Pump
Pump Type
Gear Pump
Axial Piston Pump
Main Pump Capacity
110 Lpm
125 Lpm
Main Pump Capacity
110 Lpm
125 Lpm
Max Hydraulic Flow
220 Lpm
320 Lpm
Max Hydraulic Flow
220 Lpm
320 Lpm
System Pressure
250 bar
280 bar
System Pressure
250 bar
280 bar
Service Capacities
Engine Oil
16 L
28 L
Engine Oil
16 L
28 L
Rear Axle Oil
18 L
20 L
Rear Axle Oil
18 L
20 L
Transmission Oil
18 L
40 L
Transmission Oil
18 L
40 L
Hydraulic System
300 L
450 L
Hydraulic System
300 L
450 L
Fuel Tank
220 L
350 L
Fuel Tank
220 L
350 L
Cooling System
25 L
45 L
Cooling System
25 L
45 L
Steering & Brakes
Steering Type
Fully Hydraulic Power Steering
Hydraulic Power Steering
Steering Type
Fully Hydraulic Power Steering
Hydraulic Power Steering
Turning Radius
7.5 m
12 m
Turning Radius
7.5 m
12 m
Service Brake Type
Full Air Dual Line Brakes
Pneumatic Dual Circuit Air Brake
Service Brake Type
Full Air Dual Line Brakes
Pneumatic Dual Circuit Air Brake
Parking Brake Type
Spring Actuated, Air Released
Spring Actuated Air Brake
Parking Brake Type
Spring Actuated, Air Released
Spring Actuated Air Brake
Tyres
Tyre Size
14.00 x 25 – 20 PR
385/95 R25
Tyre Size
14.00 x 25 – 20 PR
385/95 R25
No. of Tyres
4
8
No. of Tyres
4
8
Electrical & General
Battery
24V / 150 Ah
24
Battery
24V / 150 Ah
24
Alternator Output
70 A
70 A
Alternator Output
70 A
70 A
Max Travel Speed
40 km/h
75 km/h
Max Travel Speed
40 km/h
75 km/h
ACE 40XW
Pros
- High lifting capacity: 40 T is robust for heavy construction, industrial and infrastructure tasks.
- Telescopic boom with wide reach: Boom from ~10.3 m up to ~32.8 m for versatile applications (multiple working radii).
- Rough terrain mobility: 4×4 drive and earth‑mover tyres enhance traction and stability on uneven sites.
ZOOMLION QY55D
Pros
- Rated for 55 t, suitable for heavy construction, industrial, and infrastructure projects.
- Main boom ~43.6 m with optional jib up to ~59.5 m, providing excellent height & reach.
- Truck-mounted 4-axle design lets you drive between sites without transport trailers.
