Schwing Stetter ZL48GV

Ex-Showroom Price

₹ 70 L - 78 L

Diesel

17300 kg

N/A

Download Schwing Stetter ZL48GV Brochure

Download Schwing Stetter ZL48GV brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Schwing Stetter ZL48GV

Engine Power

230 HP

Operating Weight

17300 kg

Bucket capacity

3 Cu.m

Tipping Load

12000 kg

Dump Height

3 mm

Top Speed

40 km/h

About Schwing Stetter ZL48GV Overview

Schwing Stetter ZL48GV is a highly popular Wheeled Loader in India. Schwing Stetter ZL48GV offers an optimal full-turn static tipping load (FTSTL). Schwing Stetter ZL48GV is quite justifiable, given t...

Schwing Stetter ZL48GV Specifications & Features

Engine

Engine ModelWeichai WP7G

Engine MakeWeichai Power

Engine Type4-stroke turbocharged diesel

Engine Power230 HP

Gross Power (ISO 14396)169 kW

Net Power (ISO 9249)165 kW

Displacement7500 L

Number of Cylinders6 Nos

AspirationTurbocharged with intercooler

Rated RPM2200 rpm

Emission StandardBS III

Max Torque1050 Nm

Fuel TypeDiesel

Power Train

Transmission TypePower shift transmission

Drive Type4WD

Torque Converter TypeSingle-stage, single-phase

Gearbox TypeCountershaft (2 forward / 2 reverse)

Differential TypeConventional differential

Brakes & Steering

Service Brake TypeAir-assisted hydraulic disc brakes

Parking Brake TypeDrum type / mechanical

Steering TypeArticulated hydraulic steering

Steering Angle35 deg

Axle And Final Drive

Front Axle TypeHeavy-duty drive axle

Rear Axle TypeOscillating axle

Oscillation Angle12 deg

Final Drive TypePlanetary / hub reduction

Schwing Stetter ZL48GV EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹1,53,487

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount	₹69,00,000
Interest Amount (12 %)	₹23,09,201
Total Amount Payable	₹92,09,201

Schwing Stetter ZL48GV Pros and cons

Pros

230 HP Weichai engine → strong performance for heavy-duty work

5,000 kg payload → suitable for quarry, batching plants, and aggregates

1000 Nm → better low-speed pulling and loading efficiency

Cons

Detailed hydraulic performance data not widely available

38 km/h compared to some competitors reaching 40+ km/h

129 L → frequent refueling for long shifts

Download Schwing Stetter ZL48GV Brochure PDF

Download Schwing Stetter ZL48GV brochure online. Check out the Schwing Stetter ZL48GV PDF brochure at Only Heavy with all features and specifications.

Schwing Stetter ZL48GV Uses

Excavation

Digging

Construction

Material handling

Trenching
