Liebherr L 566

Ex-Showroom Price

₹ 1.25 Cr - 1.75 Cr

Diesel

23450 kg

N/A

Download Liebherr L 566 Brochure

Download Liebherr L 566 brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Liebherr L 566

Engine Power

272 HP

Operating Weight

23450 kg

Bucket capacity

4.2 Cu.m

Tipping Load

15900 kg

Dump Height

3.5 mm

Top Speed

40 km/h

About Liebherr L 566 Overview

The Liebherr L 566 is a high-performance heavy-duty wheel loader engineered for demanding applications in mining, quarrying, construction, ports, and large-scale material handling where maximum produc...

Liebherr L 566 Specifications & Features

Engine

Engine ModelLiebherr D946

Engine MakeLiebherr

Engine Type4-stroke turbocharged diesel

Engine Power272 HP

Gross Power (ISO 14396)230 kW

Net Power (ISO 9249)220 kW

Displacement10600 L

Number of Cylinders6 Nos

AspirationTurbocharged with intercooler

Rated RPM1800 rpm

Emission StandardBS IV

Max Torque1450 Nm

Fuel TypeDiesel

Power Train

Transmission TypeHydrostatic

Drive Type4WD

Torque Converter TypeNA

Gearbox TypeContinuously variable

Differential TypeAutomatic limited-slip differentials

Brakes & Steering

Service Brake TypeWet multi-disc brakes

Parking Brake TypeSpring-applied, hydraulically released

Steering TypeArticulated hydraulic steering

Steering Angle40 deg

Axle And Final Drive

Front Axle TypeHeavy-duty planetary axle

Rear Axle TypeOscillating planetary axle

Oscillation Angle12 deg

Final Drive TypePlanetary reduction

Liebherr L 566 EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹2,75,831

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount	₹1,24,00,000
Interest Amount (12 %)	₹41,49,869
Total Amount Payable	₹1,65,49,869

Liebherr L 566 Pros and cons

Pros

Hydrostatic / XPower driveline reduces fuel consumption significantly
Up to 310 HP → strong performance in mining & heavy-duty work
Wide range (3.5–12 m³) → suitable for quarry, coal, aggregates

Cons

Higher upfront cost than brands like some Asian competitors
Spare parts and servicing are costly (especially outside Europe/metro areas)
25-ton machine → needs special transport arrangements

Download Liebherr L 566 Brochure PDF

Download Liebherr L 566 brochure online. Check out the Liebherr L 566 PDF brochure at Only Heavy with all features and specifications.

Liebherr L 566 Uses

Excavation

Digging

Construction

Material handling

Trenching
