Tata Hitachi EX 200LC Tunnel

Ex-Showroom Price

₹ 62 L - 64.98 L

Diesel

19600 kg

3280 mm

Download Tata Hitachi EX 200LC Tunnel Brochure

Download Tata Hitachi EX 200LC Tunnel brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Tata Hitachi EX 200LC Tunnel

Engine Power

133 HP

Operating Weight

19600 kg

Bucket capacity

0.8 Cu.m

Hydraulic system

421 L/min

Maximum Digging Depth

3280 mm

Boom Height

3.55 m

About Tata Hitachi EX 200LC Tunnel Overview

The Tata Hitachi EX 200LC Tunnel is a specialized 20-ton class machine engineered specifically for underground excavation and tunneling applications where durability, precision, and safety are critica...

Tata Hitachi EX 200LC Tunnel Specifications & Features

Engine

Engine ModelCummins 6BT5.9C (6‑cyl inline, water‑cooled diesel)

Gross Power98 kW

Net Power97 kW

Engine Power133 HP

Displacement5900 cc

Number of Cylinders6 Nos

Rated RPM2000 rpm

Emission StandardBS IV

Max Torque538 Nm

Fuel TypeDiesel

Operating Weights

Operating Weight19600 kg

Machine Weight19600 kg

Counterweight4211 kg

Ground Pressure46 kPa

Hydraulic System

Main Pump TypeVariable displacement axial piston pumps

Maximum Hydraulic Flow442 L/min

Maximum System Pressure320 bar

Hydraulic Oil Capacity220 litres

Auxiliary Hydraulic Flow120 L/min

Working Range

Maximum Digging Depth3280 mm

Maximum Vertical Wall Digging Depth2725 mm

Maximum Reach at Ground Level7415 mm

Maximum Dumping Height6370 mm

Maximum Cutting Height9160 mm

Boom Length3.550 m

Arm Length2450 mm

Bucket Breakout Force150 kN

Arm Tear-out Force110 kN

Tata Hitachi EX 200LC Tunnel EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹1,35,691

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount	₹61,00,000
Interest Amount (12 %)	₹20,41,468
Total Amount Payable	₹81,41,468

Tata Hitachi EX 200LC Tunnel Pros and cons

Pros

Cummins engine is proven and serviceable, offering decent power for medium earthmoving work.
Generally considered fuel efficient for the class. (Generic EX 200LC comparisons show good fuel economy vs some competitors.)
Able to perform digging, loading, trenching, and even tunneling tasks effectively in confined spaces.

Cons

At ~₹62 L ex‑showroom, it can be pricier than some other brands’ equivalent machines (depending on features and boom/arm config).
At ~133 PS (~131 HP), rival models in the 20‑ton segment sometimes offer higher HP/torque options.
Specific tunnel version reviews are sparse online, so real‑world feedback may require dealer/test operator inputs.

Download Tata Hitachi EX 200LC Tunnel Brochure PDF

Download Tata Hitachi EX 200LC Tunnel brochure online. Check out the Tata Hitachi EX 200LC Tunnel PDF brochure at Only Heavy with all features and specifications.

Tata Hitachi EX 200LC Tunnel Uses

Excavation

Digging

Construction

Material handling

Trenching
