JCB 380LC QM

Ex-Showroom Price

₹ 57 L - 60 L

Diesel

36770 kg

6726 mm

Download JCB 380LC QM Brochure

Download JCB 380LC QM brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of JCB 380LC QM

Engine Power

284 HP

Operating Weight

36770 kg

Bucket capacity

1.4 Cu.m

Hydraulic system

304 L/min

Maximum Digging Depth

6726 mm

Boom Height

6.4 m

About JCB 380LC QM Overview

JCB 380LC QM is a popular excavator in the construction vehicle industry. The max operating weight of this excavator is 36770 Kg and also has a lifting capacity of 9170 Kg. Moreover The max digging de...

JCB 380LC QM Specifications & Features

Engine

Engine ModelJCB DieselMax 7.2 L CRDI, Turbocharged, Intercooled

Gross Power212 kW

Net Power212 kW

Engine Power284 HP

Displacement7200 cc

Number of Cylinders6 Nos

Rated RPM2000 rpm

Emission StandardBS VI

Max Torque1150 Nm

Fuel TypeDiesel

Operating Weights

Operating Weight36770 kg

Machine Weight36770 kg

Counterweight7652 kg

Ground Pressure78 kPa

Hydraulic System

Main Pump TypeTwin variable displacement axial piston type

Maximum Hydraulic Flow304 L/min

Maximum System Pressure348 bar

Hydraulic Oil Capacity430 litres

Auxiliary Hydraulic Flow241 L/min

Working Range

Maximum Digging Depth6726 mm

Maximum Vertical Wall Digging Depth6200 mm

Maximum Reach at Ground Level10866 mm

Maximum Dumping Height6898 mm

Maximum Cutting Height5241 mm

Boom Length6.450 m

Arm Length2630 mm

Bucket Breakout Force245 kN

Arm Tear-out Force201 kN

JCB 380LC QM EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹1,24,569

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount	₹56,00,000
Interest Amount (12 %)	₹18,74,134
Total Amount Payable	₹74,74,134

JCB 380LC QM Pros and cons

Pros

Powerful engine & torque: 284 hp class power (212 kW) for tough applications like quarrying and stone cutting.

Heavy-duty design: Built for quarry work with reinforced boom/arm and robust undercarriage.

Large bucket capacity: ~1.4 – 1.8 m³ buckets for high productivity in earth/rock handling.

Cons

Price variability & availability: Official pricing often not widely published, making comparison and budgeting harder; dealer quotes vary.

Heavy machine logistics: At ~36.7 t operating weight, transport and setup costs can be significant.

Specialized niche: Quarry Masters are optimized for quarry work; may be overkill for general construction or light earthmoving tasks.

Download JCB 380LC QM Brochure PDF

Download JCB 380LC QM brochure online. Check out the JCB 380LC QM PDF brochure at Only Heavy with all features and specifications.

JCB 380LC QM Uses

Excavation

Digging

Construction

Material handling

Trenching
