Schwing Stetter XGC60

Ex-Showroom Price

₹ 31 L - 33 L

Diesel

60000 kg

52 m

Download Schwing Stetter XGC60 Brochure

Download Schwing Stetter XGC60 brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Schwing Stetter XGC60

Engine Power

266 HP

Operating Weight

46300 kg

Lifting Capacity

60000 kg

Lifting Height

52 m

Working Radius

52 m

Drive Type

2WD

About Schwing Stetter XGC60 Overview

Schwing Stetter XGC60 is a highly popular crane in India. Schwing Stetter XGC60 is quite justifiable, given the features it offers. This machine comes with a boom length of 52 Meter. In addition,the m...

Schwing Stetter XGC60 Specs & Features

Engine

Engine MakeWeichai

Engine ModelWP7G270E301

Engine Type4-Stroke, Inline Diesel

AspirationTurbocharged

Gross Power198 HP

Net Power190 HP

Engine Power266 HP

Engine Displacement7000 cc

No. of Cylinders6

Fuel TypeDiesel

Rated RPM2100

Emission StandardBS IV

Max Torque1150 Nm

Power Train

Transmission TypePower Shift

Drive Type2WD

Clutch TypeWet Multi-Plate

No. of Forward Speeds2

No. of Reverse Speeds2

Gear Box TypePlanetary Gearbox

Differential TypeCrawler

Boom & Lifting

Crane TypeCrawler Crane

Boom TypeLattice Boom

Boom Length52 m

No. of Boom SectionsMultiple Pin-Connected Sections

Boom Extension TypePin-Joint Extension

Max Lifting Height52 m

Max Working Radius52 m

Rated Capacity

Max Lifting Capacity60 t

Rated Load60 t

Capacity at Min Radius60t@3

Capacity at Max Radius5t@48

Load Moment240 tm

Fly Jib

Fly Jib Length15 m

Fly Jib AvailableYes

Max Height with Fly Jib65 m

Speed

Max Travel Speed1.6 km/h

Creep Speed0.4 km/h

Dimensions

Overall Length12500 mm

Overall Width3400 mm

Overall Height3250 mm

Wheelbase3866 mm

Min Ground Clearance450 mm

Wheel Track Front2876 mm

Wheel Track Rear2987 mm

Schwing Stetter XGC60 EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹66,733

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount	₹30,00,000
Interest Amount (12 %)	₹10,04,001
Total Amount Payable	₹40,04,001

Schwing Stetter XGC60 Pros and cons

Pros

High lift capacity: 60 tonne makes it suitable for heavy lifting projects.

Robust engine: 266 HP diesel engine delivers strong performance for continuous operation.

Versatile boom: 13 – 52 m boom length allows a wide range of lift heights for various applications.

Cons

Price not widely published: Buyers must request customized quotes — less transparent pricing.

Heavy unit weight: At ~46 + tonnes, transport & logistics costs can be high.

Lower travel speed: Typical for crawler cranes; not ideal for sites requiring frequent relocation.

Download Schwing Stetter XGC60 Brochure

Download Schwing Stetter XGC60 brochure online. Check out the Schwing Stetter XGC60 PDF brochure at Only Heavy with all features and specifications.

Schwing Stetter XGC60 Uses

Construction Lifting

Material Handling

Infrastructure Projects

Heavy Lifting

Tower Construction
