Century Knuckle Boom

Ex-Showroom Price

₹ 7 L - 9 L

Diesel

Diesel

12000 kg

12000 kg

22 m

22 m

Download Century Knuckle Boom Brochure

Download Century Knuckle Boom brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Century Knuckle Boom

Engine Power

Engine Power

180 HP

Operating Weight

Operating Weight

16000 kg

Lifting Capacity

Lifting Capacity

12000 kg

Lifting Height

Lifting Height

22 m

Working Radius

Working Radius

18 m

Drive Type

Drive Type

4WD

About Century Knuckle Boom Overview

Century Cranes is a very popular name in the heavy construction equipment segment. Century Cranes Knuckle Boom is designed with segment best specification, which helps in providing better work efficie...

Century Knuckle Boom Specs & Features

Engine

Engine MakeTata / Ashok Leyland
Engine Model5.7L / H Series
Engine Type4-Stroke Turbocharged Diesel
AspirationTurbocharged with Intercooler
Gross Power147 HP
Net Power140 HP
Engine Power180 HP
Engine Displacement5800 cc
No. of Cylinders6
Fuel TypeDiesel
Rated RPM2400
Emission StandardBS VI
Max Torque850 Nm

Power Train

Transmission TypeManual
Drive Type4WD
Clutch TypeSingle Plate Dry Clutch
No. of Forward Speeds9
No. of Reverse Speeds1
Gear Box TypeSynchromesh
Differential TypeHeavy Duty Hypoid

Boom & Lifting

Crane TypeTruck Mounted Knuckle Boom Crane
Boom TypeArticulated (Knuckle Boom)
Boom Length18 m
No. of Boom Sections5
Boom Extension TypeHydraulic Telescopic
Max Lifting Height22 m
Max Working Radius16 m

Rated Capacity

Max Lifting Capacity12000 t
Rated Load14 t
Capacity at Min Radius14T @ 2 m
Capacity at Max Radius2 – 3T @ 14 m
Load Moment32 tm

Fly Jib

Fly Jib Length5 m
Fly Jib AvailableYes
Max Height with Fly Jib24 m

Speed

Max Travel Speed80 km/h
Creep Speed2 km/h

Dimensions

Overall Length10500 mm
Overall Width2500 mm
Overall Height3500 mm
Wheelbase5200 mm
Min Ground Clearance250 mm
Wheel Track Front1900 mm
Wheel Track Rear1800 mm

Century Knuckle Boom EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹13,347

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount₹6,00,000
Interest Amount (12 %)₹2,00,800
Total Amount Payable₹8,00,800

Century Knuckle Boom Pros and cons

like

Pros

  • High flexibility of movement
  • Works in tight spaces
  • Compact folding boom
    • like

    Cons

  • Lower max reach vs telescopic cranes
  • Capacity reduces quickly with reach
  • Higher initial cost

    • Download Century Knuckle Boom Brochure

    Download Century Knuckle Boom brochure online. Check out the Century Knuckle Boom PDF brochure at Only Heavy with all features and specifications.

    Century Knuckle Boom Uses

    uses

    Construction Lifting

    uses

    Material Handling

    uses

    Infrastructure Projects

    uses

    Heavy Lifting

    uses

    Tower Construction
