ACE F 250

Ex-Showroom Price

₹ 54 L - 58 L

Diesel

25000 kg

19 m

Download ACE F 250 Brochure

Download ACE F 250 brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of ACE F 250

Engine Power

101 HP

Operating Weight

25000 kg

Lifting Capacity

25000 kg

Lifting Height

19 m

Working Radius

20 m

Drive Type

4WD

About ACE F 250 Overview

ACE F 250 is a highly popular Crane in India. In addition the max travel speed of the ACE F 250 crane is 37 Kmph. ACE F 250 comes with an engine which generates a power of 101 HP. In addition, this en...

ACE F 250 Specs & Features

Engine

Engine MakeVolvo Eicher

Engine ModelE483 CRDI

Engine Type4-Stroke, Water-Cooled Diesel

AspirationTurbocharged with Intercooler

Gross Power74 HP

Net Power72 HP

Engine Power101 HP

Engine Displacement4760 cc

No. of Cylinders4

Fuel TypeDiesel

Rated RPM2200

Emission StandardCEV Stage IV

Max Torque400 Nm

Power Train

Transmission TypeManual Synchromesh

Drive Type4WD

Clutch TypeSingle Plate, Dry Type

No. of Forward Speeds10

No. of Reverse Speeds2

Gear Box TypeHeavy Duty Synchromesh

Differential TypeLimited Slip Differential

Boom & Lifting

Crane TypePick & Carry Crane

Boom Type3-Section Telescopic Boom

Boom Length8.5 m – 19.3 m m

No. of Boom Sections3

Boom Extension TypeHydraulic Telescopic

Max Lifting Height19 m

Max Working Radius20 m

Rated Capacity

Max Lifting Capacity25 t

Rated Load25 t

Capacity at Min Radius25 tons @ 2.5 m

Capacity at Max Radius3.5 tons @ 18 m

Load Moment62.5 tm

Fly Jib

Fly Jib Length5 m

Fly Jib AvailableYes

Max Height with Fly Jib24 m

Speed

Max Travel Speed40 km/h

Creep Speed1.5 km/h

Dimensions

Overall Length10200 mm

Overall Width2500 mm

Overall Height3350 mm

Wheelbase3600 mm

Min Ground Clearance350 mm

Wheel Track Front2000 mm

Wheel Track Rear2000 mm

ACE F 250 EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹1,17,896

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount	₹53,00,000
Interest Amount (12 %)	₹17,73,734
Total Amount Payable	₹70,73,734

ACE F 250 Pros and cons

Pros

Capable of handling up to 25 tonnes — above many 20-ton pick-and-carry competitors.

Volvo-Eicher CEV Stage IV engine offers modern fuel-efficiency and reduced emissions vs older engines.

4WD helps handle rough terrain and site mobility.

Cons

Price is typically on request from dealers rather than a transparent list.

20.5 tonnes curb weight affects transport logistics.

Hoist speed ~35 m/min is slower than some competitors.

Download ACE F 250 Brochure

Download ACE F 250 brochure online. Check out the ACE F 250 PDF brochure at Only Heavy with all features and specifications.

ACE F 250 Uses

Construction Lifting

Material Handling

Infrastructure Projects

Heavy Lifting

Tower Construction
